FEATURES:
SPECIFICATION:
| Capacity | 4” pipe and larger, flat plate. |
| Pipe Wall/ Plate Thickness | Min 0.188" (4.8 mm)/Max 0.50" (12.7 mm). |
| Models Equipped with – | 37.5°; 30° or 45° (with Optional Cutter Heads). |
| Cutter Head | Rated for most steel & stainless steel*. |
| Size | 15.8 in. (401 mm) L x 11.5 in. (292 mm) W x 13.3 in. (338 mm) H. |
| Land Width | 0" - 3/16" (4.8 mm) in approximately 1/32" (0.8 mm) increments. |
| Motor Type | Universal single-phase. |
| Motor RPM | 950 (no load). |
| Body | Steel frame |
